1. Overview
The Model HSHD-3070 Constant Speed Mixer is designed to mix cements.
As deeper wells are being drilled, heavier weight cements are needed to withstand higher downhole pressures. The Model HSHD-3070 has a heavy-duty motor that can handle thicker cements at the proper speed. The mixer has control buttons that the operator can use to program the proper mixing speeds and times. One control button can reach to 12,000 rpm. These programming features save the operator time.
2.Features and Specifications
The mixer is mainly composed of frame, mud cup and cup holder ,etc.
- Frame: The structure is used to support the main body of the instrument.
- Mud Cup: It is Used to hold samples.
- Cup Holder: It is Used to hold mud cup .
3.Main Technical Parameters
| Category | Specification |
| Power | AC(220±11)V 50Hz 230W |
| Constant Rotational Speed | 4000
12000 (r/min) |
| Stepless Speed Regulation | 0~12000r/min |
| Mud Cup Capacity | 1000ml |
