Overview

The HSHD Electronic Balance is an advanced device that integrates precision, stability, and automation. It employs high-precision strain gauge sensors and tactile feedback buttons to simplify operation and ensure accurate measurements. Equipped with a glass windproof cover, it minimizes external environmental interference and ensures reliable weighing performance. An optional dual-screen display provides bidirectional reading capability, making it suitable for applications in industrial, agricultural, commercial, pharmaceutical, educational, and other sectors.

Main Technical Parameters

Model	HSHD-10002
Weight Range	0-1000g
Accuracy of Reading	10mg
Plate Size	Φ120mm
Peeling Area	gamut
Linear Error	±0.03g
Repeatability Error	±0.03g
Net Weight	2.6kg
Stability Time (Typical)	≤2s
Measurement Unit	g/kg/ct/T/TAR/dr/PKT/GN/TMR/gsm/tlj/mo/dwt/oz/lb/tlT/ozt/tlH
Power	AC220V～DC9V 500mA, 50Hz, 5W
Function	* Full-scale weighing with peel-off function * Basic weighing * Automatic zeroing * Counting function with adjustable sample count * Multiple unit conversions: g (grams), kg (kilograms), ct (carats), oz (ounces), lb (pounds) * Automatic device detection upon power-on * Automatic calibration (external calibration) * Linear calibration (requires a complete set of weights) * RS232 interface available for connection to computers or microprinters * Two printing output modes * Automatic fault alarm
Characteristic	* Fully transparent design * Expanded weight measurement range * External power supply * Intelligent backlighting control for clear readings * Large LCD display with high-contrast fonts
