1.Overview
The Model 833 Rig Laboratory is a portable kit that contains materials and equipment for measuring slurry properties. This kit allows laboratory-quality measurements of viscosity, specific gravity, density, and sand content. All testing instruments are contained in a high-impact plastic carrying case. This case is durable, compact, and customized for storing each item. Users can make rapid, onsite measurements in the lab, field, or on the drilling rig.
2.Model and Specifications
| Model | Name |
| HSHD-833 | Rig Laboratory |
3.Main Technical Parameters
The standard 833 Rig Laboratory includes testing equipment to test drilling fluids for weight, marsh funnel viscosity and sand content.
| Name | Model |
| Mud Balance | HSHD-5002 |
| Marsh Funnel Viscometer | HSHD-2006 |
| Sand Content Test Kit | HSHD-1302 |
3.1 Specifications
Refer to the following table for detailed Specifications.
Model HSHD-5002 Mud Balance
| Category | Specification |
| Measurement Range | 0.96-2.5g/cm3 |
| Measurement Accuracy | 0.01g/ cm3 (0.1lb/gal) |
| cup capacity | 140 cm3 |
Model HSHD-2006 Marsh Funnel Viscometer
| Category | Specification |
| Mesh Size | 1.6mm (12 mesh) |
| Volume of Funnel | 1500ml |
| Accuracy | When injecting 1500ml of standard distilled water into the funnel, the time for 946ml of standard distilled water to flow out is 26 ± 0.5s |
Model HSHD-1302 Sand Content Test Kit
| Category | Specification |
| Filter mesh aperture | 0.074mm（200 mesh） |
| Glass measuring cylinder capacity | 100ml |
| Sand content | 0～20% |
