1.Overview
The temperature control part of Model HSHD-1103 Roller Oven adopts the latest microcomputer intelligent control technology, which directly sets the temperature, displays it digitally, and can provide deviation indication with high accuracy. Work is safe and reliable. In addition, there are power and electrical control systems installed on the upper part of the furnace body for easy use, maintenance, and repair.
Main purpose:
1. Study the cation exchange reactions that occur in the re prepared drilling fluid (such as calcium treated drilling fluid).
2. Determine the stability of drilling fluid additives (such as various diluents and organic gels).
3. Make adrying oven.
4. Create an aging oven.
5. Used as a ball mill.
6. Stir chemical solution.
7. Uniformly mix liquid or solid substances.
8. Remove gas from the liquid.
2.Model and Product Name
| Model | Product Name |
| HSHD-1103 | Roller Oven |
3.Main Technical Parameters
| No. | Category | Specification |
| 1 | Power Supply | 220V±5% 50Hz |
| 2 | Motor Power | 200W |
| 3 | Heating Power | 750W×2 |
| 4 | Operating Temperature Range | Room temperature~232℃ |
| 5 | Aging cell Speed | 50r/min |
| 6 | Temperature Control Accuracy | ±2℃ |
| 7 | Sample Flow Rate Inside the Cell | 0.16 m/s |
