Atmospheric Consistometer HSHD-1252

The HSHD-1252 Atmospheric Consistometer is designed and manufactured in strict accordance with API Specification 10. It is used for the curing process of cement slurry fluid loss tests under ambient temperature and atmospheric pressure conditions, as well as for cement curing in free-fluid tests. The unit features an all stainless-steel housing for long-lasting durability.

Inquiry Us

Overview
The HSHD-1252 Atmospheric Consistometer is designed and manufactured in strict accordance with API Specification 10. It is used for the curing process of cement slurry fluid loss tests under ambient temperature and atmospheric pressure conditions, as well as for cement curing in free-fluid tests. The unit features an all stainless-steel housing for long-lasting durability.

Features
1.Equipped with an OMRON temperature controller for high-precision temperature
control.
2.Equipped with an OMRON timer relay with alarm function.
3.Stainless steel rotating mechanism for corrosion resistance.
4.Quiet geared motor for low-noise operation.

Parameter
1.Power Supply: AC220V (±10%) 50Hz 3kW
2.Motor Speed: 150±5rpm
3.Digital PID closed-loop control with digital display
4.Working Temperature Range: Ambient ∼ 100℃
5.Temperature Control Accuracy: <±1℃
6.Slurry Cup Capacity: 465ml × 2
